7x60W Aura Bee Eye & Zoom Moving Head IP20

The IP20 7x60W Aura bee eye & zoom moving head .It features seven 60W high-power LED beads, a ring LED halo, and bee eye effects. It supports wide zoom .It can achieve multiple effects such as bee eye dot matrix, halo fill light, and zoom wash light. The head-mounting is flexible and the positioning is precise. It is suitable for outdoor performances, cultural and tourism lighting, large-scale commercial performances, and other scenarios for creating atmosphere and core lighting. For martin MAC Aura XIP.

Get a Free Quote

Get Product Catalogs

◼

Why Choose Us

Key Features & Benefits

• Safe and Reliable: Compliant with CE and RoHS certifications.

• Cost-Effective: Factory-direct supply; supports bulk OEM/ODM orders.

• Easy Maintenance: Simple structural design results in lower maintenance costs.

• Extreme Environment Adaptability: IP65 waterproof rating; features a full die-cast aluminum housing for excellent heat dissipation, along with temperature control and overheat protection functions.

• Customization Options: Optional laser-printed logo available.

◼

Parameters

General Specifications

The 7x40W RGBW 4-in-1 Bee Eye Wash Light Aura features 7 × 60W RGBW LEDs and 12 × 3W RGB Aura filaments for zoom wash, bee-eye matrix, halo and pixel effects. With 7°-45° zoom, 1-25Hz strobe, 0-100% dimming, 540° pan, 270° tilt, DMX512/RDM, optional Art-Net, RGBW color mixing and OLED display, it is ideal for stage shows, commercial events and cultural tourism lighting.

Technical Specifications
Voltage	AC90-240v 50-60HZ	Rated power	550W
Light source	7x 60W（4in1 RGBW）high brightness LEDs	Filament Aura	12x 3W (3in1 RGB) LED filament
Beam angle	7-45°	Strobe	1-25HZ with multiple strobe effects
Dimming	Four dimming effect (Linear/Square/I Sequare/Scurve) 0-100% linear dimming.	Channel	Built-in 6 channel modes 21/30/36/57/78/93CH
Control	DMX512，Auto，RDM, Art-Net (Support for additional installation)	Pan	540°+16bit fine
Tilt	270°+16bit fine	Optical effect	High precision integrated structure PMMA lens, high transparency quartz glass light pipe, creating a softer dyeing range. Latest Aura filament pixel effect.
Color	RGBW color mixing with very bright and vibrant saturated colors, as well as soft pastels and white tones. Tungsten Emulation Option.Virtual Color Wheel.	Macro effects	Multiple built-in macros with control of foreground color, background color, speed and direction. 3D video mapping of fixture beam pixels and/or Aura filaments. High-speed pan, tilt and zoom
Temperature control	Intelligent temperature control, capable of automatically adjusting the speed of the cooling fan and overheating protection	Body material	Latest second-generation structural waterproof design, metal die-casting aluminum shell and fire-resistant and UV resistant engineering plastic
IP Rating	IP20	Display	1.77-inch OLED screen, Chinese and English menu, anti-interference photoelectric signal isolation system, waterproof intelligent touch key (screen activation password 1111)
Fixture dimension	35.6×28×45cm	Carton size（1pc/ctn)	43.53652.5cm
NW.: 14.6kg GW.	18.5 kg

◼

Download

Download File

Download the IP20 7×60W B Eye User Manual for the 7×40W RGBW 4-in-1 Bee Eye Wash Light Aura. This PDF provides product operation guidance, DMX512/RDM control information, channel mode settings, installation notes and maintenance instructions for professional stage lighting use.
