Wash Zoom 19*20w moving head
- Technical Specification
- Product Details
Light Sources: 19*20W 4IN1 RGBW LED
Average life span> 50000 hours
Beam Angle:5.8°- 55°
Glass light guide + PMMA high quality optical lens
Power Consumption: 350w
Power factor PF≥0.95
Working temperature: -10℃～45℃
Power Voltage: AC 100-240V, 50/60Hz
Dimension: 338*254*37.5mm
Net Weight: 8.5kgs
Carton package 1in1 size: 42*34*46cm
Carton package 1in2 size: 69*44*48cm
Control
DMX Channel:19/27 Channels
Control Modes: DMX512/mater-Slave/Auto Run/Music
Pan/Tilt
Pan: 540°/ 360°, Tilt: 270°
Pan/Tilt Resolution: 8/16 bit
Construction
Display:180° reversible 1.8 inch TFT colorful Display
DataIn/Out socket: 3-pin & 5-pin XLR sockets
Power Socket: Power Con in/out
Protection Rating: IP20
Features
Circle control effects, 3 circle control.
High-efficiency optical system, wonderful flower effect plus zoom
Fan work speed auto adjustable with head temperatur
Wash Zoom 19*20w moving head
Light Sources: 19*20W 4IN1 RGBW LED
Average life span> 50000 hours
Beam Angle:5.8°- 55°
Glass light guide + PMMA high quality optical lens
Power Consumption: 350w
Power factor PF≥0.95
Working temperature: -10℃～45℃
Power Voltage: AC 100-240V, 50/60Hz
Dimension: 338*254*37.5mm
Net Weight: 8.5kgs
Carton package 1in1 size: 42*34*46cm
Carton package 1in2 size: 69*44*48cm
Control
DMX Channel:19/27 Channels
Control Modes: DMX512/mater-Slave/Auto Run/Music
Pan/Tilt
Pan: 540°/ 360°, Tilt: 270°
Pan/Tilt Resolution: 8/16 bit
Construction
Display:180° reversible 1.8 inch TFT colorful Display
DataIn/Out socket: 3-pin & 5-pin XLR sockets
Power Socket: Power Con in/out
Protection Rating: IP20
Features
Circle control effects, 3 circle control.
High-efficiency optical system, wonderful flower effect plus zoom
Fan work speed auto adjustable with head temperatur
